26
System description
2.12.2 Multiwired probes
This range of probes (see table 5) is compatible with the PH10M and PH10MQ heads
only and utilise the Renishaw multiwired autojoint connection to the head.
Table 5 - Multiwire probe
Probe Application Diameter Weight User’s guide
SP25M High speed
scanning probe
25 mm Body
SM25-1
SM25-2
SM25-3
TM25-20
65 g
35 g
40 g
49 g
40 g
H-1000-5104
All without stylus
TP7M Universal probe
with strain gauges
for DCC CMMs.
25 mm 85 g (without stylus) H-1000-5010
SP600M* Analogue contact
scanning probe
50 mm 216 g (without stylus) H-1000-5175
OTP6M Laser non-contact
optical trigger
probe
49 mm 253 g (fitted with PEM1) H-1000-5007
Probes in this range require comprehensive integration with your CMM.
* WhenusingaPH10MQwithSP600M,aPEM25extensionbarisrequiredto
achieve A = 97.5° or A = 105° in all B-axis positions.
See figure 9.
2.13 Probe extension bars
Renishaw manufactures a comprehensive range of extension bars and adaptors
to allow increased component penetration (see figures 8 and 9 for allowable
combinations).
