30
Accessories
3
Accessories
3.1
Adjustment modules
The AM1 adjustment module shown in figure 13 is designed f
or use on the PH10T and
PH10M.
Lock/unloc
k screw
Roll
Pitch
Ya
w
Overtrav
el
Figure 13 -
AM1 adjustment module
31
