22
System description
2.10 PH10 probe carrying capability
Figure 8 shows the range of extensions, probes and styli which can be used in
conjunction with the PH10T head.
Figure 8 - Extensions, probes and styli
PH10T
PEL1
PEL2
PEL3
PEL4
TP6
TP20
TP2-5W
TP200
M3 thread styliM2 thread styli
AM1
