System description
2.7 Probe head specification
Table 1 - Probe head specification
Repeatability of
position (2s)
PH10T
<0.4µm(0.00002in)-equivalenttoaTP20
and stylus (part number A-5000-3604)
PH10M
PH10MQ
<0.4µm(0.00002in)-equivalenttoaTP6A
and stylus (part number A-5000-3553)
Accuracy of step
spacing from
theoretical position
PH10T
±0.24 mm (±0.012 in)
(using TP6 probe and stylus part number
A-5000-3553)
PH10M
PH10MQ
±0.3 mm (±0.012 in)
(using TP6A probe and stylus part number
A-5000-3553)
Positioning
Step 7.5°
A axis 0° to 105° 15 positions
B axis -180° to +180° 48 positions
Total 720 positions
Probe
mounting
PH10T M8 thread, 18 mm (0.709 in) diameter bush
face
PH10M
PH10MQ
Multiwired autojoint
Dimensions
from quill
face
XY 62 mm (2.44 in) square
Z
PH10T 102 mm (4.09 in)
PH10M 117 mm (4.6 in)
PH10MQ 73 mm (4.6 in)
Weight
PH10T 595 g (20.9 oz)
PH10M 620 g (21.8 oz)
PH10MQ 730 g (25.7 oz)
System operating temperature
10 °C to 40 °C (50 °F to 104 °F)
System storage temperature
-10 °C to 70 °C (14 °F to 158 °F)
