Renogy REGO Quick Guide

— 7 —
Battery Scenario B: Normal Battery Kit
+
-
+
-
Battery Voltage Sensor
Through the grommet
of the COM Port
1 2
-
+
-
Step 7. Install a Battery Temperature Sensor
The temperature sensor measures the surrounding temperature of the battery and compensates the floating
charge voltage when the battery temperature is low.
Do not use the temperature sensor on a LiFePO4 (LFP) battery which comes with a battery
management system (BMS).
+
-
Battery Temperature Sensor
Mount the sensor securely
at a suitable location in
close proximity to the battery.
Through the grommet
of the COM Port

Renogy REGO Specifications

General

Output Voltage	12V/24V
Output Current	20A
Charging Algorithm	Multi-stage (Bulk, Absorption, Float)
Battery Compatibility	Flooded, Lithium
Operating Temperature	-20°C to 50°C
Protection	Over-voltage, Short-circuit, Reverse polarity
Communication	Bluetooth
Cooling Method	Fan
