Renogy REGO Quick Guide

— 16 —
Configuration Panel
INV LED Indicator
Battery Type Setting Knob
AC IN LED Indicator
BAT LED Indicator
AC Output Priority Setting
On/O/Remote Power Switch
AC Output Frequency Setting
Buzzer ON/OFF
Set a Battery Type
Upon installing the inverter charger, set a correct battery type by using the Battery Type Setting Knob.
It is essential to ensure that the battery type setting is configured correctly to avoid any potential
damage to the inverter charger because any damage to the inverter charger resulting from an
incorrect battery type setting voids the warranty.
Lithium Battery
Flooded Battery SLD/AGM Battery
USER Gel Battery

Renogy REGO Specifications

General

Output Voltage	12V/24V
Output Current	20A
Charging Algorithm	Multi-stage (Bulk, Absorption, Float)
Battery Compatibility	Flooded, Lithium
Operating Temperature	-20°C to 50°C
Protection	Over-voltage, Short-circuit, Reverse polarity
Communication	Bluetooth
Cooling Method	Fan
