Renogy REGO Quick Guide

— 6 —
Step 5. Install a Wired Remote Control
You can use a Wired Remote Control to power on or off the inverter charger remotely.
RJ12 Cable
ON ERR
RMS-P2
Through the grommet
of the COM Port
Step 6. Install a Battery Voltage Sensor
The Battery Voltage Sensor measures the battery voltage during discharging and compensates for any voltage
drop across the cables at the battery terminal. This helps minimize the impact on the battery’s operational
voltage.
Battery Scenario A: REGO Battery Kit
+
-
Battery Voltage Sensor
Through the grommet
of the COM Port
1 2

Renogy REGO Specifications

General

Output Voltage	12V/24V
Output Current	20A
Charging Algorithm	Multi-stage (Bulk, Absorption, Float)
Battery Compatibility	Flooded, Lithium
Operating Temperature	-20°C to 50°C
Protection	Over-voltage, Short-circuit, Reverse polarity
Communication	Bluetooth
Cooling Method	Fan
