ResMed AIRMINI Clinical Guide

10
Setting up the AirMini system
Before setting up the machine, ensure that the selected mask is compatible and that it is correctly
positioned on the patient's face. The machine is compatible with ResMed's F20 and N20 series
masks and with the P10 for AirMini. Refer to the mask device compatibility list on
www.resmed.com for more information. Refer to the mask user guide for fitting information.
See Using clinical mode for information on preparing to use the AirMini app with a smart device.
Setting up the machine
1. Plug the power supply unit to the
machine and the power outlet.
The connector has an angled edge so that
the power cord can only be inserted into
the machine one way.
2. Connect the grey end of the air tubing
firmly to the air outlet.
Adding optional humidification
For N20 or AirFit P10 for AirMini only:
To insert the HumidX or HumidX Plus:
1. Open the connector by gently twisting it.
2. Hold the HumidX/HumidX Plus with the
colored side pointing down and insert it.
3. Gently push together the connector and twist
until it locks in place.
Connecting your mask
Attach the connector to the mask.
F20 Series N20 Series AirFit P10 for AirMini

ResMed AIRMINI Specifications

General

Type	Travel CPAP machine
Pressure Range	4-20 cm H2O
Noise Level	30 dBA
Bluetooth	Yes
Operating Mode	CPAP, AutoSet
Sound Level	30 dBA
Altitude Adjustment	Automatic
Operating Temperature	41°F to 95°F (5°C to 35°C)
Weight	0.66 lbs
Power Supply	AC 100-240V, 50-60Hz
Humidification	Optional, with HumidX/HumidX Plus waterless humidification
Data Storage	Via AirMini app
Power Consumption	6.3W
Ramp Time	0 to 45 min (5-minute increments)
Compatible Masks	AirFit P10, AirFit N20, AirFit F20
Operating Humidity	10 to 95% relative humidity, non-condensing
