ResMed AIRMINI Clinical Guide

English 19
Cleaning and replacing parts
After detaching all components according to the disassembly instructions, ensure that the HumidX
or HumidX Plus is removed and stored in a clean, dry location.
Inspecting the HumidX or HumidX Plus
1. Inspect the HumidX or HumidX Plus daily for any signs of damage or blockages caused by dirt or
dust.
2. Replace the HumidX or HumidX Plus within 30 days after opening it.
3. Store the HumidX or HumidX Plus in a clean, dry location when it is not being used.
Note: The HumidX and HumidX Plus cannot be washed.
Cleaning the AirMini tubing
1. Clean and check the AirMini tubing each week. AirMini tubing should be replaced at least every
six months.
2. Wash the AirMini tubing in warm water using a mild, liquid detergent.
3. Rinse the AirMini tubing thoroughly and allow it to dry out of direct sunlight and heat.
4. Check the AirMini tubing and replace it if there are any holes, tears or cracks.
Note: Do not wash the AirMini tubing in a dishwasher or washing machine.
Cleaning the F20 connector
1. Clean and check the F20 connector daily. The connector should
be replaced at least every six months.
2. Wash the F20 connector in warm water using a mild, liquid
detergent.
3. Clean the F20 connector with a soft-bristled brush, paying
particular attention to the vent holes.
4. Rinse the F20 connector thoroughly under running water.
5. Shake the F20 connector to remove excess water.
6. Allow the F20 connector to dry out of direct sunlight and heat.
7. Ensure that there is no dirt or dust in the vent holes.
Note: Do not wash the F20 connector in a dishwasher or washing
machine.
Cleaning the N20 connector
1. Clean and check the N20 connector daily. The connector should
be replaced at least every six months.
2. Wash the N20 connector in warm water using a mild, liquid
detergent.
3. Clean the N20 connector with a soft-bristled brush, paying
particular attention to the vent holes inside the connector.
4. Rinse the N20 connector thoroughly under running water.
5. Shake the N20 connector to remove excess water.
6. Allow the N20 connector to dry out of direct sunlight and heat.
7. Ensure that there is no dirt or dust in the vent holes.
Note: Do not wash the N20 connector in a dishwasher or washing
machine.

ResMed AIRMINI Specifications

General

Type	Travel CPAP machine
Pressure Range	4-20 cm H2O
Noise Level	30 dBA
Bluetooth	Yes
Operating Mode	CPAP, AutoSet
Sound Level	30 dBA
Altitude Adjustment	Automatic
Operating Temperature	41°F to 95°F (5°C to 35°C)
Weight	0.66 lbs
Power Supply	AC 100-240V, 50-60Hz
Humidification	Optional, with HumidX/HumidX Plus waterless humidification
Data Storage	Via AirMini app
Power Consumption	6.3W
Ramp Time	0 to 45 min (5-minute increments)
Compatible Masks	AirFit P10, AirFit N20, AirFit F20
Operating Humidity	10 to 95% relative humidity, non-condensing
