Insert the mains plug (IEC C14) of the industrial vacuum cleaner into the IEC power
connection (L) on the backside of the AS 200 jet.
Switch on the industrial vacuum cleaner.
The industrial vacuum cleaner is supplied with power by the AS 200 jet and switched on
automatically via software control at the beginning of the sieving process.
The industrial vacuum cleaner connected to the IEC power connection (L) can also be used
to clean the device. For that purpose, the industrial vacuum cleaner can be switched on
manually via the control unit ( Chapter "Controlling the Device").
Chemical reactivity
Mixing of different sample materials
Successive analyses of different sample materials may cause unwanted
chemical reactions that can lead to fires or explosions.
• Do not analyse any sample materials in this device that carry a risk
of increasing chemical reactivity by contact with a previously
analysed substance.
• If in doubt, clean the device and the industrial vacuum cleaner (incl.
changing the vacuum cleaner bag and filter) before analysing any
other sample material.
• Observe the material safety data sheets of the sample materials.
5.5 Inserting the Test Sieve
The AS 200 jet is designed for test sieves with an outer diameter of 203 mm (8") and a height of
50 mm (2") or 25 mm (1"). Test sieves with an outer diameter of 200 mm can also be used in
combination with an adapter ring (AR).
Fig. 8: Inserting a test sieve with an outer diameter of 203 mm (left) or 200 mm (right)
