Commissioning 43/60
RE 92100-01-B/09.2012, A4VSG Series 10, 11 and 30, Bosch Rexroth AG
8 Commissioning
WARNING
Danger while working in the danger zone of a machine/system!
Danger to life, risk of injury or serious injuries!
▶ Pay attention to and rectify potential danger sources before operating the axial
piston unit.
▶ Nobody may stand in the danger zone of the machine/system.
▶ The emergency stop button for the machine/system must be within the
operator’s reach.
▶ Always follow the instructions of the machine/system manufacturer during
commissioning.
CAUTION
Commissioning of an incorrectly installed product!
Risk of injury and damage to equipment!
▶ Make sure that all electrical and hydraulic ports are connected or plugged.
▶ Only commission a completely installed fault-free product with original
accessories from Bosch Rexroth.
8.1 First commissioning
During all work for commissioning the axial piston unit, observe the general
safety instructions and intended use detailed in chapter2 "Safety instructions" on
page9.
▶ Connect the pressure gauge for the operating pressure, case pressure, boost
pressure and suction pressure to the specified measuring points on the axial
piston unit or in the hydraulic system, to check the technical data at first
operation.
▶ During the commissioning process, monitor the temperature of the hydraulic fluid
in the reservoir to ensure that it lies within the permissible viscosity limits.
8.1.1 Filling the axial piston unit
Professional filling and air bleeding is necessary to prevent damage to the axial
piston unit and to maintain correct function.
The axial piston unit should be filled with a filling unit (10μmfilter grade). The
axial piston unit must not be operated while it is being filled by the filling unit.
