RGBlink CP 3072PRO - Input Menu; Output Menu

Chapter 3: Using Your Product
CP 3072PRO User Manual
21
There are 7 menu items in the main menu, and display in 2 pages. Turn the rotary knob, and
select any menu above, push the rotary knob to confirm, the OLED display will show the
submenu. If push the MENU button, the OLED display will return to the last level menu.
3.3.3 Input Menu
Ch.1~Ch.8
Ch.1~Ch.8
Select the signal for Ch. 1~Ch. 8.
Input Format
Show the input format of Ch. 1~Ch. 8.
Ch.1 Control~Ch.8 Control
If select HDMI, HActive, VActive and Freq can be set. If select USB, file
number, play mode, duration of picture, order, play state can be set. User
can also select if upgrade by USB.
3.3.4 Output Menu
->Input >>
Output >>
Background >>
Advance >>
->Language/语言 >>
System >>
Factory Reset >>
->Ch.1 In 1-1 USB
Ch.2 In 1-2 USB
Ch.3 In 1-3 USB
Ch.4 In 2-1 HDMI
->Ch.5 In 2-2 HDMI
Ch.6 In 2-3 HDMI
Ch.7 In 3-1 SDI
Ch.8 In 3-2 SDI
->Format 1920×1080×60
Custom Format >>
4K1K >>
Color Space/Sample/Bit >>
