CP 3072PRO provides 3 input option slots, range of inputs are available for user fitting,
including DVI, VGA, HDMI, USB, CVBS, DP and SDI.
DVI-I – DVI
Each DVI module supports 1 DVI-I input. Standard DVI signals can input. The DVI port
supports up to HDMI 1.3 if the port format is set to HDMI.
DB15 – VGA
Each VGA module supports 1 DB15 input. Standard VGA signals can input.
HDMI-A – HDMI
Each HDMI module supports 1 HDMI-A input and 1 HDMI loop out. Standard HDMI
signal from computer can input. And can connect to the HDMI input of the next CP
3072PRO or the device with HDMI input.
USB-A– USB
Each USB module supports 1 USB-A input and 1 USB backup. Access the USB device or
mobile hard disk with USB storage function. Support general image and video formats.
BNC – CVBS
Each CVBS module supports 1 BNC input and 1 BNC backup. Standard video signal from
players, cameras can input.
DP
Each DP module supports 1 DP input. Standard DisplayPort signals can input.
BNC – 3G-SDI
Each SDI module supports 1 SDI input and 1 SDI loop out. Standard 3G-SDI signals can
input. And can connect to the SDI input of the next CP 3072PRO or the device with SDI
input.
