RGBlink CP 3072PRO User Manual

Chapter 3: Using Your Product
CP 3072PRO User Manual
25
Blending Width
Set the blending width, the adjustment range is between 1~90.
ON/OFF
Enable or disable the Blending function.
DSK
Layer
Select the layer.
Preset
Select user, black background, green background, blue background, red
background and white background.
Mode
Select Key In or Key Out.
Alpha
The adjustment range is between 0~128.
Red Min
The adjustment range is between 0~255.
Red Max
The adjustment range is between 0~255.
Green Min
The adjustment range is between 0~255.
Green Max
The adjustment range is between 0~255.
Blue Min
The adjustment range is between 0~255.
Blue Max
The adjustment range is between 0~255.
DSK
Select “ON” or “OFF” to enable or disable DSK function.
3.3.7 Language Menu
Language/语言
Select Chinese or English.
3.3.8 System Menu
->Language/语言 English
->Version >>
Ethernet >>
T-BAR Calibration >>
Test >>
