41
14. Place the electrodes on or around the
treatment area. You can choose to use one
channel or two channels but must have at least
two electrodes placed on the patient as shown
in the figure to the left. Electrodes should
be at least 2” but no more than 6” apart, per
channel..
15. For safety purposes, the load detection
function was designed so when the output
intensity surpasses 10.0mA/10.0V, and there
are no electrodes placed on the patient’s
skin or the device has not been connected
to electrodes, an alarm buzzer will sound
and the intensity value will flash and reset to
zero. Note: If the pulse duration is less than
80
μs, the load detection function will activate
when output intensity surpasses or equal
40.0mA/40.0V.
16. Press the [STOP] button to stop treatment
if any emergency or error happened.
CAUTION:
1. For device protection, a temperature
detection feature was designed to stop
electrical stim when temps reach over 160°F.
The device will not work again unless the
temperature reaches 140°F.
2. To protect the patient, the device will stop
ultrasound intensity output and the LED
on the applicator will flash if the applicator
temperature over 107°F. It will resume again
when the temperature below 105°F.
17. Press the Central controller dial to pause a
channel, press the corresponding channel knob
on the top of the device and then press the
central controller dial to pause that channel.
Each channel must be paused individually.
STOP
