Ricoh Aficio MP C4502 General Settings Guide

Registering Addresses and Users for Facsimile/Scanner Functions
224
7
C Press [TNext].
D Press [Address Book Management].
E Check that [Program / Change] is selected.
F Select the name whose folder you want to register. Press the name key, or
enter the registered number using the number keys.
If you press , you can search by the registered name, user code, fax number,
folder name, e-mail address, or IP-Fax destination.
G Press [Auth. Info], and then press [TNext].
H Press [Specify Other Auth. Info] on the right side of Folder Authentication.
When [Do not Specify] is selected, the SMB User Name and SMB Password that
you have specified in Default User Name / Password (Send) of File Transfer
settings applies.
I Press [Change] under "Login User Name".
J Enter the login user name, and then press [OK].
K Press [Change] under "Login Password".
L Enter the password, and then press [OK].
M Enter the password again to confirm, and then press [OK].
N Press [Folder].
O Check that [SMB] is selected.
To specify a folder, you can either enter the path manually or locate the folder
by browsing the network.
P Press [Connection Test] to check the path is set correctly.
Q Press [Exit].
If the connection test fails, check the settings, and then try again.

Ricoh Aficio MP C4502 Specifications

General

Print Technology	Laser
Maximum Print Resolution	1200 x 1200 dpi
Maximum Paper Capacity	4, 400 sheets
Automatic Duplexing	Yes
Maximum Scan Resolution	600 dpi
Fax Capability	Optional
Maximum Paper Size	12" x 18"
Memory (Standard)	1.5 GB
Hard Drive	250 GB
Copy Resolution	600 x 600 dpi
Print Speed	45 ppm
Standard Paper Capacity	1, 200 sheets
Scanner Type	Flatbed, ADF
Network Connectivity	Ethernet
Functions	Print, Copy, Scan
Copy Speed	Up to 45 ppm (Black/Color)
Fax Speed	33.6 kbps
Operating System Compatibility	Windows, Mac, Linux
