Ricoh Aficio MP C4502 General Settings Guide

Interface Settings
53
2
❖ LAN Type
When you have installed the IEEE 802.11b interface unit, select the method of
connection.
The default setting is Ethernet.
[LAN Type] is displayed when wireless LAN board is installed. If Ethernet and
IEEE 802.11b (wireless LAN) are both connected, the selected interface has
priority.
❖ Ping Command
Check the network connection with ping command using given IP address.
If you fail to connect to the network, check the following, and then retry the
ping command.
• Make sure that “TCP/IP” in [Effective Protocol] is set to “Effective”.
• Check that the machine with assigned IP address is connected to the net-
work.
• There is a possibility that the same IP address is used for the specified
equipment.
❖ Permit SNMP V3 Communication
Set the encrypted communication of SNMPv3.
The default setting is Encryption / Clear Text.
If you select to [Encryption Only], you need to set an encryption password for
the machine.
❖ Permit SSL / TLS Communication
Set the encrypted communication of SSL / TLS.
The default setting is Ciphertext Priority.
If you set to [Ciphertext Only], you need to install the SSL certificate for the ma-
chine.
❖ Host Name
Specify the host name.
Enter the host name using up to 63 characters.
❖ Machine Name
Specify the machine name.
Enter the machine name using up to 31 characters.

Ricoh Aficio MP C4502 Specifications

General

Print Technology	Laser
Maximum Print Resolution	1200 x 1200 dpi
Maximum Paper Capacity	4, 400 sheets
Automatic Duplexing	Yes
Maximum Scan Resolution	600 dpi
Fax Capability	Optional
Maximum Paper Size	12" x 18"
Memory (Standard)	1.5 GB
Hard Drive	250 GB
Copy Resolution	600 x 600 dpi
Print Speed	45 ppm
Standard Paper Capacity	1, 200 sheets
Scanner Type	Flatbed, ADF
Network Connectivity	Ethernet
Functions	Print, Copy, Scan
Copy Speed	Up to 45 ppm (Black/Color)
Fax Speed	33.6 kbps
Operating System Compatibility	Windows, Mac, Linux
