x Clearing Misfeeds
57
4
When a master misfeed occurs on the drum
A Lift the lever to unlock the drum unit and pull out the unit.
Reference
For how to remove the drum unit, see p.33 “Changing the Color Drum
Unit”.
B Remove the master from the drum.
C Re-insert the drum unit until the drum unit locks in position and put the
lever back in place.
1
22
TSLH031E
