Ricoh D127 - Paper Tray Unit

Specifications
SM Appendix 1-11 D127/D128
Appendix:
Specifications
Power Consumption: T.B.D
Dimensions (W x D x H): 485 x 450 x 120 mm
Weight: 3kg or less
1.1.6 PAPER TRAY UNIT
Paper Sizes:
A4 SEF, 8½" x 11" SEF, 8½" x 13" SEF,
8½" x 14" SEF
Paper Weight: 60 – 90 g/m
2
, 16 – 24 lb.
Tray Capacity: 500 sheets (80 g/m
2
, 21 lb. ) x 1 tray
Paper Feed System: Feed roller and friction pad
Power Source:
24 Vdc and 5 Vdc, from copier. If optional tray heater is
installed, the copier also supplies Vac (120 Vac or
220 – 240 Vac).
Power Consumption: Maximum: 15 W (excluding optional tray heater)
Average: 14 W (excluding optional tray heater)
Weight: Not above 6 kg (13.2. lb.)
Size (W x D x H): 430 x 414 x 140 mm (16.9" x 16.3" x 5.5")
 2 units can be installed at maximum. When more than 3 units are installed, SC occurs
and the operation doesn’t work.
