Ricoh GR III - USB Power Adapter AC-U1;AC-U2; Rechargeable Battery DB-110

7
Appendix
151
USB Power Adapter AC-U1/AC-U2
Power Supply 100 to 240 VAC (50/60 Hz), 0.2 A
Output 5.0 VDC, 1000 mA, 5.0 W
Average Active Efficiency*
1
76.8%
No-Load Power Consumption*
1
70 mW
Temperature 10 to 40°C (50 to 104°F)
Dimensions 42.5 mm (W) × 22 mm (H) × 66.5 mm (D) (1.7 in. (W) × 0.9 in. (H) ×
2.6in. (D)) (excluding the power plug)
Weight Approx. 40 g (1.4 oz) (excluding the power plug)
*1 AC-U2 only
Rechargeable Battery DB-110
Nominal Voltage 3.6 V
Rated Capacity 1350 mAh, 4.9 Wh
Operating Temperature 0 to 40°C (32 to 104°F)
Storage Temperature -10 to 45°C (14 to 104°F)
Dimensions 39.8 mm (W) × 34.2 mm (H) × 8.5 mm (D) (1.6 in. (W) × 1.3 in. (H)
× 0.3 in. (D))
Weight Approx. 26 g (0.9 oz)
