❖ ADF
Note
❒ Originals are normally rectangular ( ) or horizontally long ( ). However, the
table above uses squares to make original orientation easier to understand.
Even if the actual shape of the original is different, the combination of original
orientation and the orientation specified on the scanner driver does not
change.
❒ When you specify Full Colour, Gray Scale, or Auto Colour Select for Scan
Type, and single page TIFF/JPEG or multi-page TIFF is selected as the file
type, refer to the table below for how to place originals. Originals placed in
orientations that are not recommended in the table might appear incorrectly
top/bottom oriented on client computer displays.
Original orientation Control Panel Key
top edge placed first
top edge touches rear of ADF
