Ricoh SG 3110DN User Manual

Loading Paper
Load paper into the paper tray.
• When loading paper, take care not to trap or injure your fingers.
Loading Paper into Tray 1-3
1. Hold the tray grip, pull the tray halfway out, lift it slightly ( ), and then pull it out further
( ).
1
2
CHU053
Pull the tray out completely. Take care not to drop it.
After pulling the tray out, check that no paper remains in the machine. If there is any remaining
paper sheets, remove it.
2. Pinch the catch of the paper guide on the right side, slide the paper guides to match the
size of paper you want to load, and then push the end paper guide out until there is
space between them.
CHU098
2. Preparing for Printing
100

Ricoh SG 3110DN Specifications

General

Paper Capacity	250 sheets
Connectivity	USB 2.0, Ethernet
Duplex Printing	Yes
Operating System Compatibility	Windows, Mac OS, Linux
Print Resolution	3600 x 1200 dpi
Print Speed	29 pages per minute
Paper Size	A4, A5, A6, B5
Print Technology	Gel-based inkjet
