Ricoh SG 3110DN - Loading Paper into Bypass Tray

9. Push the tray gently in until it stops.
1
2
CTW015
10. Pull out the output ramp extension.
CTW016
• Do not use the tray extension for A4 (Letter) size paper or smaller paper.
Loading Paper into Bypass Tray
1. Pull out the bypass tray extension and adjust the position of the paper guide to match the
size of the paper you want to load.
CTW055
Extend the bypass tray so that it matches the paper size.
Loading Paper
105
