Ricoh SG 3110DN User Manual

2. Open the rear unit cover and remove the jammed paper.
See page 235 "Opening the Rear Unit Cover to Remove Jammed Paper (SG 3110DN/SG
3110DNw)".
• Continue to remove the jammed paper according to subsequent error messages until the messages
no longer appear. See page 224 "Paper Jam".
• If paper jams occur repeatedly, see page 222 "Paper Is Not Fed or Delivered Normally".
Opening the Rear Cover to Remove Jammed Paper
1. Slide the tabs on the sides to unlock, and then open the rear cover.
CHU088
2. Remove the jammed paper.
CHU089
8. Troubleshooting
232

Ricoh SG 3110DN Specifications

General

Paper Capacity	250 sheets
Connectivity	USB 2.0, Ethernet
Duplex Printing	Yes
Operating System Compatibility	Windows, Mac OS, Linux
Print Resolution	3600 x 1200 dpi
Print Speed	29 pages per minute
Paper Size	A4, A5, A6, B5
Print Technology	Gel-based inkjet
