1. Close the cover.
Top cover
CHU059
Rear cover
CHU066
Make sure to return the tabs to their original positions.
Duplex unit cover
CHU064
To open the duplex unit cover, you need to detach the multi bypass tray. Reattach it after you close
the duplex unit cover.
If the multi bypass tray is attached to the machine, turn the machine off and detach the multi bypass
tray. See page 30 "Attaching and Detaching the Multi Bypass Tray".
Status Monitor Errors
257
