Ricoh SG 3110DN User Manual

4. Attach the anti-topple stand, and then secure it with a coin screw. (SG 7100DN)
CTW027
If the paper feed unit is in use, attach the anti-topple stand to it.
CTW007
5. Attach the multi bypass tray while pressing the tabs on each side, and then push it in all
the way. (SG 3110DN/SG 3110DNw) Attach the multi bypass tray into the machine until
you hear it click. (SG 7100DN)
CHU083
Make sure to return the tabs to their original positions.
If the tabs do not return to their original positions, push the tray in while pulling up on its top left part
as shown.
Attaching and Detaching Units and Options
31

Ricoh SG 3110DN Specifications

General

Paper Capacity	250 sheets
Connectivity	USB 2.0, Ethernet
Duplex Printing	Yes
Operating System Compatibility	Windows, Mac OS, Linux
Print Resolution	3600 x 1200 dpi
Print Speed	29 pages per minute
Paper Size	A4, A5, A6, B5
Print Technology	Gel-based inkjet
