Specify a number between 1 and 10 for the IPsec policy. The number you specify will
determine the position of the policy in the IPsec Policy List.
•
[Activity]
Select whether to enable or disable the policy.
• [Name]
Enter the name of the policy. Can contain up to 16 characters.
• [Address Type]
Select IPv4 or IPv6 as the type of IP address to be used in IPsec communication.
• [Local Address]
Displays the IP address of this printer.
• [Remote Address]
Enter the IPv4 or IPv6 address of the device with which to communicate.
Can contain up to 39 characters.
• [Prefix Length]
Enter the prefix length of the Remote Address, using a value between 1 and 128. If this setting
is left blank, "32" (IPv4) or "128" (IPv6) will be automatically selected.
• [Action]
Specify how the IP packets are processed from the following:
• [Allow]
IP packets are both sent and received without IPsec applied to them.
• [Drop]
IP packets are discarded.
• [Require Security]
IPsec is applied to IP packets that are both sent and received.
If you have selected [Require Security], you must configure [IPsec Settings] and [IKE
Settings].
IPsec Settings
• [Encapsulation Type]
Specify the encapsulation type from the following:
• [Transport]
Select this mode to secure only the payload section of each IP packet when
communicating with IPsec compliant devices.
• [Tunnel]
4. Configuring the Machine Using Utilities
52
