Punch Selection and Firing
[A]: Punch Drive Motor (M24)
[B]: Punch Encoder Wheel
[C]: Punch Encoder Sensor (S24)
[D]: Punch HP Sensor (S23)
The punch drive motor (M24) [A] turns the small, notched encoder wheel [B] through the gap in the punch
encoder sensor [C] (S24). The sensor output is used to control the punch timing.
Punch Unit B702 (For B804/B805)
75
