Drawing plate
Figure 2-7: Example drawing plate
The drawing plate states:
Drawing number
Product plate
Figure 2-8: Example product plate
The product plate states:
Production number
2.5.2 Quality control
Every HortiJet Pro is checked and tested for correct operation before shipment. The
corresponding certificate can be found in the documentation included with the unit.
When the HortiJet Pro has been checked, it will be labelled with a control sticker. You
will find this sticker on the inside of the cabinet.
Figure 2-9: Example control sticker.
The sticker shows:
Name of inspector.
Date inspected.
Inspector’s signature.
HortiJet Pro
17
