4.1.4 Electrical installation requirements
The requirements are:
Ensure that there is a stable power source.
Ensure that there are sufficient extra plug sockets near the unit to operate,
maintain and install it.
Ensure that the equipment and the electricity network is grounded (earthed).
4.2 Step-by-step installation and commissioning
instructions
The overview below provides a step-by-step plan. You can follow this when installing
and configuring the HortiJet Pro.
This procedure assumes that:
Synopta and the HortiMaX CX500 are installed.
the dealer is familiar with the CX Assistant.
No. Step Section to see for this
Installation
1 Water installation
Connect the HortiJet to the two
branches from the main pipe.
Connect the fertilizer supply hoses to
the dosing channels.
"Connecting water supply
(hydronic installation)" on
the next page.
2 Electrical installation
Connect the power supply, network
cable, main irrigation pump and
external meters and valves.
"Connecting electrical
components" on page27.
3 Where applicable: connect the extra dosing
channels, sensors and/or I/O modules.
"Installing other
components" on page28.
Commissioning
4 Use the latest version of the software for the
CX Assistant, HortiMaX CX500 and Synopta.
"Updating software" on
page30.
5 Software configuration
Create a configuration with the CX
Assistant.
Check the configuration.
Upload the configuration to the IPC.
"Software configuration" on
page31.
6 Check the settings (for the controls HortiMaX
CX500) in Synopta.
"Software settings" on
page36.
7 Calibrate the EC and pH sensors. "Calibrating the sensors" on
page37.
