4 Installation
This section is intended for the dealer of the HortiJet Pro.
This section describes the following subjects:
Installation requirements
Connecting the various components
In section "Step-by-step installation and commissioning instructions" on
page25 you will find an overview of the steps. Use the Bijlage: "Checklist for
step-by-step installation procedure" on page52 to check that all steps have
been completed.
4.1 Installation requirements
This section describes the requirements for installing the HortiJet.
4.1.1 Dealer/installer requirements
The installation of the HortiJet Pro and the other components, together with the
installation and configuration of the software, must be carried out by a qualified
dealer. Ridder Growing Solutions considers a dealer/installer to be qualified if that
person meets the following requirements:
The dealer:
has successfully completed the HortiJet Pro and HortiMaX CX500 training
courses at Ridder Growing Solutions.
has a broad knowledge of installation technology (hydronic and electronic).
has experience with Microsoft Windows® controlled computer systems (in a
network environment) from version 8 upwards.
can understand and carry out instructions in English.
is familiar with the contents of this installation and user manual.
4.1.2 Installation requirements
The following requirements apply to installing the HortiJet Pro on site:
Make sure that the HortiJet Pro is level.
Install the HortiJet Pro on a hard surface that is able to support its weight.
Install the unit in a dry, dust-free location(1)
1
.
Check the ambient temperature. This should be between 5°C - 30°C (41°F -
86°F) (2).
Check the relative humidity (RV). This may not exceed 85%, without
condensation (3).
Make sure that the unit is not exposed to dripping or splashing water (4).
1
The numbers refer to the numbers in Figure 4-1.
HortiJet Pro
22
