Figure 5-1: Location of the PRVs and the PSV on the HortiJet Pro.
No. Name No. Name
1 Pressure gauge, PRV2. 4 Pressure gauge, PRV1.
2 PRV2. 5 Pressure gauge, PSV.
3 PRV1. 6 PSV.
Adjusting the valves
The PRV1 and PSV consist of a valve with a plastic rotary knob and a navaton pilot
that can be adjusted by using the metal bolt.
Figure 5-2: Components of PRV1 and PSV.
