43
output voltage and current.
Max Power is set to 740W by default, you can set it between
0-740W, it is the max output power. On the top you can see the *1
icon, it is the adjustment magnification, you can press
or to
choose the different
magnification so that you can set the value quickly,
The max output is default voltage priority mode, when the setting
voltage*setting current is higher than the max power, the device will
automatically
decrease the output current setting value. When used together
with low power power source, it is recommended to set the value as
the rated power of the power source*95%
(default setting no need to
edit);
Temperature unit is ℃ by default, it can be switched between ℃ and ℉(Figure 6);
Battery Charger Sub-menu(
Figure 7
):
Cut-Off Current is set to 10mA by default and it can be edited. On the top you can see the *1
icon, it is the adjustment magnification, you can press
or to choose the different
magnification so that you can set the value quickly, when the real output current is lower than this
set value, the output will be cut off automatically.
Cut-Off Temp. is set to 60℃ by default, when the external temperature sensor detect over 60℃,
the output will be cut off automatically.
Communication Sub-menu(
Figure 8
):
Interface is set to USB by default, you can also set it to
WIFI/TTL/RS45, USB means the micro USB port, you can see on
the top when set it USB, and when the communication starts, it will
show ; You need to insert a WIFI board to use the WIFI
function, and it will show on the top, and when the communication starts, it will show ; TTL
is not available now; You need to insert RS485 module to use RS485, and it will show on the
top, and when the communication starts, it will show .
