Riello RL 70 - Technical Description of the Burner; Burner Designation and Models

9
2916456
GB
Technical description of the burner
4.1 Burner designation
4.2 Models available
4 Technical description of the burner
Series : R
Size
Fuel : Natural gas
Gas oil
Gas oil / Methane
Setting :
Flame control system :
FS1
FS2
Standard (1 stop every 24 h)
Continuos working (1 stop every 72 h)
Electrical supply to the system :
1 / 230/50
3 / 230 / 50
Auxiliary voltage :
230/50/60
R L 70 TC
Emission :
... Class 1 EN267 - EN676
MZ Class 2 EN267 - Class 2 EN676
BLU Class 3 EN267 - EN676
MX
Class 2 EN267
Class 3 EN676
FS1 3/230-400/50 230/50
BASIC DESIGNATION
EXTENDED DESIGNATION
1 / 230V / 50Hz
3 / 230V / 50Hz
230V / 50-60Hz
Heavy oil
... Two stage
/M Modulating
/1 Single stage
S
L
LS
N
Head :
TC Standard head
TL Extended head
110/50/60 110V / 50-60Hz
3 / 400 / 50
3 / 230-400 / 50
3N / 400V / 50Hz
3 / 230V / 50Hz - 3N / 400V / 50Hz
3 / 220 / 60
3 / 380 / 60
3 / 220V / 60Hz
3N / 380V / 60Hz
3 / 220-380 / 60 3 / 220V / 60Hz - 3N / 380V / 60Hz
Model Code
Electrical
supply
Blast tube
lenght mm
RL 70
3471712
3471713
Three-phase
Three-phase
250
385
RL 100
3471812
3471813
Three-phase
Three-phase
250
385
RL 130
3471912
3471913
Three-phase
Three-phase
250
385
