Maintenance
8.3 Opening the burner
Remove screw 1 and withdraw the casing 2).
Unscrew screw 3).
Fit the two extensions 4) supplied with the burner onto the
slide bars 5) (model with 385 mm blast tube).
Pull part A backward keeping it slightly raised to avoid dam-
aging the disk 6) on blast tube 7).
8.4 Closing the burner
Disconnect the electrical supply from the burner
by means of the main system switch.
Close the fuel interception tap.
Wait for the components in contact with heat
sources to cool down completely.
After carrying out maintenance, cleaning or
checking operations, reassemble the hood and all
the safety and protection devices of the burner.
