Rigol DG1012

RIGOL
© 2008 RIGOL Technologies, Inc. 5-5
User’s Guide for DG10× 2 Series
(2mHz to 20kHz)
Frequency Deviation
DC~ 5 MHz
PM (CH1)
Carrier Waveforms
Sine, Square, Ramp, Arb (Except DC)
Source
Internal/ External
Modulating Waveforms
Sine, Square, UpRamp, DnRamp,Triangle, Noise, Arb
(2mHz to 20kHz)
Phase Deviation
0 to 360°
FSK (CH1)
Carrier Waveforms
Sine, Square, Ramp, Arb (Except DC)
Source
Internal/ External
Modulating Waveforms
50% duty cycle square (2mHz to 50kHz)
Sweep (CH1)
Carrier Waveforms
Sine, Square, Ramp, Arb (Except DC)
Type
Linear or Logarithmic
Direction
Up or Down
Sweep Time
1 ms to 500 s ± 0.1%
Source
Internal/External/Manual
Burst (CH1)
Waveforms
Sine, Square, Ramp, Pulse, Noise, Arb (Except DC)
Types
Count (1 to 50,000 periods), infinite, gated
Start Phase
-180° to +180°
Internal Period
1 µs – 500s ± 1%
Gate Source
External Trigger
Trigger Source
Internal/External/Manual
Rear Panel Connector
External AM Modulation
± 5 VPK = 100% modulation
5k input impedance
External Trigger
TTL-compatible
Trigger Input
