DG1000 Command System RIGOL
Programming Guide for DG1000
2-27
panel.
Return Value The query returns OFF or ON.
13. OUTPut:CH2
Syntax OUTPut:CH2 {OFF|ON}
Function Disable or enable the front-panel [Output] connector of CH2. The
default is OFF.
Example OUTP:CH2 ON
14. OUTPut:CH2?
Syntax OUTPut:CH2?
Function Query the state of front-panel [Output] connector of CH2.
Return Value The query returns OFF or ON.
15. OUTPut:LOAD:CH2
Syntax OUTPut:LOAD:CH2 {<ohm>|INFinity|MINimum|MAXimum}
Function Select the desired output termination of CH2. The specified value
is only used for amplitude and offset voltage.
Explanations  Ω is the unit of <ohm>, the default is 50Ω.
 “INFinity” sets the output terminal as “High Z”.
Example OUTP:LOAD:CH2 MIN
16. OUTPut:LOAD:CH2?
Syntax OUTPut:LOAD:CH2? [MINimum|MAXimum]
Function Query the current load setting of CH2.
Return Value The query returns the current load setting in Ω or returns “Infinity”.
17. OUTPut:POLarity:CH2
Syntax OUTPut:POLarity:CH2 {NORMal|INVerted}
Function Set the polarity of waveform output from CH2.
Example OUTP:POL:CH2 NORM
18. OUTPut:POLarity:CH2?
Syntax OUTPut:POLarity:CH2?
Function Query the polarity of waveform output from CH2.
Return Value The query returns NORM or INV.
