RIGOL DG1000 Command System
Programming Guide for DG1000
2-26
7. OUTPut:SYNC
Syntax OUTPut:SYNC {OFF|ON}
Function Disable or enable the rear panel [Sync Output] connector of CH1.
Explanation Only CH1 provides sync signal output.
Example OUTP:SYNC OFF
8. OUTPut:SYNC?
Syntax OUTPut:SYNC?
Function Query the state of the [Sync Out] connector of CH1 on the rear
panel.
Return Value The query returns SYNC OFF or SYNC ON.
9. OUTPut:TRIGger:SLOPe
Syntax OUTPut:TRIGger:SLOPe {POSitive|NEGative}
Function Select the edge of “tirgger output”.
If the OUTPut:TRIGger command is enabled, TTL-compatible
square wave with specified edge will be generated from [Ext
Trig/FSK/Burst] conncetor on the rear panel when the sweep
starts.
Explanations  The command is used in Burst and Sweep operation.
 Select “POS” to output a pulse with a rising edge.
 Select “NEG” to output a pulse with a falling edge.
Example OUTP:TRIG:SLOP POS
10. OUTPut:TRIGger:SLOPe?
Syntax OUTPut:TRIGger:SLOPe?
Function Query the edge of “tirgger output”.
Return Value The query returns POSITIVE or NEGATIVE.
11. OUTPut:TRIGger
Syntax OUTPut:TRIGger {OFF|ON}
Function Disable or enable the [Ext Trig/FSK/Burst] connector on rear panel.
Example OUTP:TRIG OFF
12. OUTPut:TRIGger?
Syntax OUTPut: TRIGger?
Function Query the state of the [Ext Trig/FSK/Burst] connector
on rear
