RIGOL DG1000 Command System
Programming Guide for DG1000
2-46
Detailed information of each command:
1. TRIGger:SOURce
Syntax TRIGger:SOURce {IMMediate|EXTernal|BUS}
Function Select the trigger source for generator, including
internal trigger
(IMM), external trigger (EXT) from the [Ext Trig/FSK/Burst]
connector on the rear panel and manual trigger (BUS). The default
is IMM.
Example TRIG:SOUR EXT
2. TRIGger:SOURce?
Syntax TRIGger:SOURce?
Function Query the trigger source of generator.
Return Value The query returns IMM, EXT or BUS.
3. TRIGger:SLOPe
Syntax TRIGger:SLOPe {POSitive|NEGative}
Function Set the generator to use the rising edge (POS) or falling edge
(NEG) of the trigger signal from the [Ext Trig/FSK/Burst] connector
on the rear panel. The default is POS (rising edge).
Explanation This command could be used only when OUTPut:TRIGger is
enabled.
Example TRIG:SLOP POS
4. TRIGger:SLOPe?
Syntax TRIGger:SLOPe?
Function Query the edge selected for trigger signal .
Return Value The query returns POS or NEG.
5. TRIGger:DELay
Syntax TRIGger:DELay {<second>|MINimum|MAXimum}
Function
Set the trigger delay in seconds. Note: this command is only
applicable to Burst mode.
Example TRIG:DEL 0.000005
6. TRIGger:DELay?
Syntax TRIGger:DELay?
