Chapter 5 Specifications RIGOL
User’s Guide for DP1308A
5-1
Chapter 5 Specifications
DP1308A Programmable Linear DC Power Supply specification and operating
characteristics are based on the instrument having been operated continuously for 30
minutes under the specified operating temperature.
NOTE:
All the specifications below apply to all the three channels output unless where noted.
Model
DP1308A
Channels
+6V
+25V
-25V
DC output (@ 0℃～40℃)
Voltage
0～+6V
0～+25V
0～-25V
Current
0～5A
0～1A
0～1A
Overvoltage Protection
0.1V～6.5V
0.1V～27V
-0.1V～-27V
Overcurrent Protection
0.1A~5.5A
0.1A～1.2A
0.1A～1.2A
Load Regulation± (output percentage + offset)
Voltage
<0.01%+2mV
Current
<0.01%+250μA
Line Regulation± (output percentage + offset)
Voltage
<0.01%+2mV
Current
<0.01%+250μA
Ripple and Noise (20 Hz~20 MHz)
Normal Mode Voltage
<350μVrms/2mVpp
Normal Mode Current
<2mArms
<500μArms
Common Mode Current
<1.5μArms
Accuracy 12 Months
[1]
(25℃± 5℃)± (output percentage + offset)
Program
ming
Voltage
0.1%+5mV
0.05%+20mV
Current
0.2%+10mA
0.15%+4mA
Read
Back
Voltage
0.1%+5mV
0.05%+10mV
Current
0.2%+10mA
0.15%+4mA
Resolution
Programming
0.5mV/0.5mA
1.5mV/0.1mA
Read Back
0.5mV/0.5mA
1.5mV/0.1mA
Meter
1mV/1mA
10mV/1mA
