Rigol DS1202/4B User Manual

RIGOL
5-2 © 2008 RIGOL Technologies, Inc.
User’s Guide for DS1000B Series
Specifications
Acquisition
Sampling Modes
Real-Time
Equivalent-time
Sampling Rate
2 GSa/s (half channel
[1]
)
1 GSa/s (each channel)
50 GSa/s
[2]
Averages
N time acquisitions, all channels simultaneously, N is
selectable from 2, 4, 8, 16, 32, 64, 128 and 256
Inputs
Input Coupling
DC, AC, GND
Input Impedance
1MΩ±2%, in parallel with 18pF±3pF
Probe Attenuation Factors
0.001X, 0.01X, 0.1X, 1X, 2X, 5X, 10X, 20X, 50X,
100X, 200X, 500X, 1000X
Maximum Input Voltage
Maximum Input Voltage of the analog channel:
CAT I 300Vrms
, 1000Vpk; transient overvoltage
1000Vpk
CAT II 100Vrms, 1000Vpk
RP2200 10:1, CAT II 300Vrms
RP3200 10:1, CAT II 300Vrms
RP3300 10:1, CAT II 300Vrms
Time delay between channel
(typical)
500ps
Horizontal
Sample Rate Range
3.65Sa/s-2GSa/s (Real-Time),
3.65Sa/s-50GSa/s (Equivalent-time)
Waveform interpolation
Sin(x)/x
Record Length
16k samples for half channel
[1]
8
k samples for each channel
Scan speed Range
(Sec/div)
1ns/div~50s/div, DS1202/4B
2
ns/div~50s/div, DS1102/4B
5ns/div
~50s/div, DS1062/4B
1-2-5 Sequence
Sample Rate and
Delay Time Accuracy
±50ppm (over any≥1ms time interval)
