User’s Guide for DS1000B series
2-88
Date and Time
DS1000B Series provide build-in system r
eal-time date and time. Users can set the
date and time as shown in the f
ollowing f
igure.
Figure 2-113
Date and time setting
Figure 2-114
T
able 2-76 Time setting menu
Menu
Settings
Comments
Display
OFF
ON
Close time display
Open time display
Move up/down the setting f
ocus
Move left/right the setti
ng focus
OK
Save the current settings
Time display
