Turn on or off Channels
CH1, CH2, CH3, CH4 and Ext. trigger channels are input channels. All functions
applied will base on operating the instrument with channels, so MATH and REF can
be regarded as relatively isolated channels.
Press the corresponding button (for example: CH1, CH2, CH3, CH4, MATH, REF) on
the front panel to turn the channels on. The backlight indicates the channel is
currently active. When a channel is currently selected, press the button with respect
to the channel again will turn it off and the backlight goes off. When a channel is not
currently selected, press the button associated with the channel will select the
channel as the current channel.
Table 2-19 The Channels menu
Channel Mode
Settings
Status Indicator
Channel 1 (CH1)
ON
Selected
OFF
CH1 (yellow letters with black background)
CH1 (black letters with yellow background)
No indicator
Channel 2
(
CH2)
ON
Selected
OFF
CH2 (sky blue letters with black background)
CH2
(black letters with blue background)
No indicator
Channel 3(CH3)
ON
Selected
OFF
CH3˄pink letters with black background˅
CH3˄black letters with pink background˅
No indicator
Channel4(CH4)
ON
Selected
OFF
CH4
˄black letter with navy blue background˅
CH4
˄navy blue letter with black background˅
No indicator
MATH
ON
Selected
OFF
Math (black letter)
Math
(purple letter)
No indicator
