Rigol DS1202/4B - General Specifications

RIGOL
5-6 © 2008 RIGOL Technologies, Inc.
User’s Guide for DS1000B Series
General Specifications
Display
Display Type
5.7 inch. (145 mm) diagonal TFT Liquid Crystal
Display
Display Resolution
320 horizontal ×RGB×240 vertical pixels
Display Color
64k color
Display Contrast (typical)
150:1
Backlight Brightness (typical)
300 nit
Probe Compensator Output
Output Voltage (typical)
Amplitude, ~3Vpp
Frequency (typical)
1kHz
Power
Supply Voltage
ACˈ100~240 V, 45~440Hz, CAT II
Power Consumption
Less than 50VA
Fuse
2A, T rating, 250 V
Environmental
Ambient
Temperature
Operating 10
ć
~ 40
ć
Non-operating -20ć~ +60ć
Cooling Method
Fan force air flow
Humidity
+35
ć
or below: ≤90% relative humidity
+35
ć
~ +40
ć
: ≤60% relative humidity
Altitude
Operating 3,000 m or below
Non-operating 15,000 m or below
Mechanical
Size
Width
325mm
Height
159mm
Depth
133 mm
Heavy
Without package
3kg
Packaged
4.3 kg
