RIGOL
© 2008 RIGOL Technologies, Inc.
User’s Guide for DS1000B Series
To Store and Recall
Figure 2-69 shows the menu button for the storage system on the front panel.
Figure 2-69
The Storage setup button
Press the Storage button to show the menu for the settings of the storage system.
Waveforms and setups can be stored in and recalled from both internal memory and
external memory. The waveform files, setup files, 8 or 24 bits format bitmap files,
CSV format files and PNG (Portable Network Graphics format) files in external
memory can be created and deleted. System supports English/Chinese file name
input.
