RIGOL Chapter 6 Operations and Measurements
6-4 DS4000E User’s Guide
the horizontal time base and horizontal position of the math operation waveform
respectively. For the adjustment methods, please refer to “To Adjust the
Horizontal Time Base” and “To Adjust the Horizontal Position”.
Note: Turning HORIZONTAL
SCALE and HORIZONTAL POSITION
will adjust the horizontal scales and horizontal positions of the channel
waveforms and math operation waveform at the same time.
5. Turn the invert on or off
Press Invert to turn the inverted display of the math operation waveform on or
off.
6. Define the math operation waveform label
Press Label to open the label submenu and the label modification interface.
Please set the math operation waveform label by referring to “
To Set the
Channel Label”.
Note: The defined label can include uppercase English letters (from A to Z),
lowercase English letters (from a to z), numbers (from 0 to 9), underline and
space; the length of the label cannot exceed 4 characters.
To Next Page
