Chapter 13 System Function Setting RIGOL
DS4000E User’s Guide 13-7
To Configure the USB Interface
This oscilloscope can communicate with PC or PictBridge printer via the USB DEVICE
interface at the rear panel. You need to set the oscilloscope to make it matchs with
different device types.
Press Utility  IO Setting  USB Device and turn the multi-function knob to
select the desired device type.
 Computer: in this mode, the oscilloscope can communicate with the PC.
 PictBridge: in this mode, the oscilloscope can communicate with the PictBridge
printer.
To Set the GPIB Address
To control the oscilloscope using the GPIB bus, you need to extend a GPIB interface
for the oscilloscope using the USB-GPIB interface converter (option, need to be
ordered separately). Then, connect the oscilloscope with the PC using a GPIB cable.
Press Utility  IO Setting  GPIB and turn the multi-function knob to select
the desired GPIB address. The range available is from 1 to 30 and the default is 1.
