Chapter 1 Quick Start RIGOL
DS4000E User’s Guide 1-11
Front Panel Overview
Figure 1-12 Front Panel Overview
Table 1-1 Front Panel Description
No. Description No. Description
1 Parameters Measurement Menu Softkeys 11 Record
2 LCD 12 Power Key
3 Multi-function Knob 13 USB HOST
4 Navigation Knob 14 Function Setting Menu Softkeys
5 HORIZONTAL 15 VERTICAL
6 CLEAR 16 Channel Input Terminals
7 AUTO 17 Function Keys
8 RUN/STOP 18 TRIGGER
9 SINGLE 19 EXT TRIG Input Terminal
10 Default and Print 20 Probe Compensation Signal Output
Terminal and Ground Terminal
12 13 14 15 16 17 18 19 20
3 4 5
6 7 8 9 10 1 2
11
To Next Page
