Chapter 12 Store and Recall RIGOL
DS4000E User’s Guide 12-7
knob to select “Local Disk” (the characters turn green) and press down
the knob to open the local disk recall interface.
3) Turn the multi-function knob to select the file to be recall; Load
becomes available and press the softkey to recall the file selected.
Tip
1. Pressing REF Import can enter the disk management interface of
reference waveform file recall.
2. Pressing Utility Pass/Fail Load can enter the disk management
interface of pass/fail test mask file recall.
To Perform External Storage and Recall
Before performing external storage and recall, make sure that the USB storage
device is connected correctly.
The external memory supports the storage of all the types of files in Storage as well
as the recall of “Traces”, “Waveform” and “Setups” files. But, the recall of “Picture”
and “CSV” files is not supported. In the following setion, the external storage and
recall methods and procedures are introduced in details.
1. Save the specified type of file in the external USB storage device (take
CSV storage as an example)
1) Connect the signal to the oscilloscope and obtain stable display.
2) Press Storage Storage; turn the multi-function knob to select
“CSV” and press the knob. You can also press Storage continuously to
switch to “CSV”.
3) Set the CSV storage parameters.
a. Press DataDepth to select “Displayed” or “Maximum”.
When “Maximum” is selected, press Channel; turn the multi-function
knob
to select the desired channel (CH1, CH2, CH3, CH4) and
press the knob or press Channel to switch the waveform data storage
state of the channel (channel group). The waveform data storage state
of the channel (channel group) is displayed at the front of the channel
(channel group) name;
denotes saving the waveform data of the
channel;
denotes not saving the waveform data of the channel.
