RIGOL Chapter 10 Waveform Recording
10-2 DS4000E User’s Guide
To Record Waveform Using the “Record” Mode
In the “Record” mode, the oscilloscope records the waveforms of all the channels
currently turned on at the specified interval until users stop the recording operation
manually or when the number of frames recorded reaches the end frame currently
set.
Note: Please turn on the desired channel and adjust the waveform display to the
desired state before starting the recording operation. After the recording operation
starts, you cannot turn on/off the channel output and adjust the waveform display.
Press Record Mode; turn the multi-function knob to select “Record” and
press the knob. You can set the recording parameters and execute the recording
operation in the waveform recording menu according to the following instructions.
1. Set the end frame
End frame refers to the number of frames that can be actually recorded. In the
“Record” mode, the oscilloscope will stop the recording operation when the
number of frames recorded reaches the preset end frame after the recording
operation starts.
Press End Frame and turn the multi-function knob or the inner knob of the
navigation knob to adjust the end frame at a relatively smaller step or turn the
outer knob of the navigation knob to adjust the end frame at a relatively larger
step. The range of the end frame is from 1 to the maximum number of frames
can be recorded currently (see Total Frames, please refer to “Maximum
Number of Frames”). The default is the maximum number of frames can be
recorded currently.
Note: The larger the rotation amplitude of the outer knob of the navigation
knob is, the faster the variation of the value will be. When you need to adjust the
end frame within a relatively larger range, this function can help you quickly
finish the setting.
